PRODUCT DESCRIPTION
Electrical Characteristics:
Mainly used in anti-interference occasions such as various power supply lines, with small high-frequency loss and small internal temperature rise
Compatc size
Plastic housing (UL94 V-0), flame retardant epoxy closure
Passed the IEC and multi-national safety standard certification
RoHS compliant
Product Structure Chart:
Production Process:
Application Area :
Certifications :
Dongguan Zhixu Electronic Co., Ltd. (also JYH HSU(JEC)) factories are ISO-9000 and ISO-14000 certified. JEC X2, Y1, Y2 capacitors and varistors have passed these certifications:
CQC (China)
VDE (Germany)
CUL (America/Canada)
KC (South Korea)
ENEC (EU)
CB (International Electrotechnical Commission)
All of our capacitors are in line with the EU ROHS directives and REACH regulations.
*FAQ:
Q: What should be paid attention to when using safety capacitors?
A: 1. The X and Y capacitors must meet the voltage requirements for use. For those exceeding the nominal voltage, you can choose to use them in series to equalize the voltage, but you must use exactly the same capacitors in series.
2. The X and Y capacitors must meet the temperature requirements. For Y capacitors, the maximum temperature during UL certification can only be 85 degrees, because the UL standard only conducts tests at a maximum of 85 degrees; but the temperature of European certification is often higher, and UL agrees to use the European certified Y capacitor temperature as the highest operating temperature.
3. Consider the size of the possible pulse voltage at the input end of the circuit. Different capacitors can withstand different pulse voltages. The withstand voltage of the capacitor cannot be less than the peak value of the pulse voltage in the circuit.
4. Safety X and Y capacitors must be certified by the safety testing agency. The appearance of capacitors is generally marked with safety certification marks (such as UL, CSA, etc.) and the words AC250V or AC275V withstand voltage. It must be emphasized that the X and Y capacitors should not be replaced by ordinary capacitors with a nominal withstand voltage of AC250V or DC400V.
