May. 12, 2023
If the capacitance of the fan capacitor is not enough, you can use two capacitors in parallel to use as one. However, the withstand voltage value of the two capacitors must not be lower than the original capacitor.
1. Sometimes the fan does not rotate for a long time, it is likely that the capacitor inside the fan is broken, we only need to replace the original capacitor with the same capacitor.
For example, the original fan was a 4uF capacitor, but there are no 4uF capacitors on hand, so we can use several in parallel. The total capacitance after parallel connection is equivalent to several capacitors connected in parallel.
2. The total withstand voltage after parallel connection is based on the lowest withstand voltage capacitor.
For example: 1uF and 3uF capacitors are connected in parallel, then their total capacitance is 1+3=4uF. A capacitor with a withstand voltage of 300V is connected in parallel with a capacitor with a withstand voltage of 450V, and the total withstand voltage is 300V.
Most electric fans on the market have only one starting capacitor, which is connected in series with the starting winding of the motor to shift the phase. If the starting capacitor fails or its capacitance drops, it will cause the motor to fail to start. Generally, we only need to replace the bad capacitor with the same type of capacitor.
If you don't have capacitors with the same capacitance on hand, you can use two capacitors in parallel, but you should pay attention to the following two points:
1. Two types of non-polar capacitors of the same type should be used for parallel capacitors. Generally, polypropylene film capacitors are used for fans.
2.The capacitance values of capacitors connected in parallel are added, but the withstand voltage value depends on the minimum value, so two capacitors with the same withstand voltage value should be selected in parallel as much as possible, and the withstand voltage value should not be less than 400 volts.
We're JYH HSU (JEC) Electronics Ltd, one of largest manufacturers in China in terms of yearly safety capacitor (X2, Y1, Y2) production. Welcome to contact us if you need electronic components.
